360° 3D-Rundumsicht-Monitor AVM-System - Alphard
Features:
This AVM system features a customized around view monitoring system for Toyota Alphard, make your driving and parking safer and more easily.
This AVM system features a customized around view monitoring system for Toyota Alphard, make your driving and parking safer and more easily.
.jpg)
.jpg?imageView2/1/w/116/w/74)
Funktionen
AHD 1080P high resolution images output
Customization designed and perfectly matched for Toyota Alphard, no impact on vehicle's appearance after installation
waterproof level: IP6K9K
auto calibration
with four wide view angle cameras, show panoramic view around the vehicle without any blind spot
Super starry night vision
OE quality standard, extra long-term warranty of 3 years
360 avm systems
Customization designed and perfectly matched for Toyota Alphard, no impact on vehicle's appearance after installation
waterproof level: IP6K9K
auto calibration
with four wide view angle cameras, show panoramic view around the vehicle without any blind spot
Super starry night vision
OE quality standard, extra long-term warranty of 3 years
360 avm systems
Leistungsbeschreibung
| Sensor | SONY IMX307 (AHD) |
| TV-Modus | PAL/NTSC |
| Bildsensor | 1/2,8 Zoll |
| Betriebsspannungsbereich | DC12V (7,5-16V) |
| Arbeitsstrom | 94mA±10mA |
| Leistungsaufnahme | 1.128W DC12 V |
| Video-Ausgang | 1,3±0,2 Vpp 75 Ω |
| NÜTZLICHE PIXEL | 1920*1080 |
| Minimale Ausleuchtung | 0,01 Lux |
| Breite Dynamik | 95 dB |
| Signal-Rausch-Verhältnis | 46 dB |
| Auflösungsverhältnis | 1080p |
| Gamma-Wert | 0.45 |
| Objektiv-Winkel | 130 Grad |
| Betrieb Luftfeuchtigkeit | 85 RH% |
| Betriebstemperatur | -20°C~ +70°C |
| Lagertemperatur | -40 °C ~ + 85 °C |
| Sonderfunktion | Super Sternen-Nachtsicht |
Anträge
